Silver Mine Motors now offers these beautifully designed and manufactured CNC 4 lug front hubs. These hubs are made of aircraft grade T6061 Aluminum. They are modeled after a 280z front hub. they use stock 280z front bearings and hub center cap. We decided to model the hub after the 280z hub instead of the 240z since the 280z hub is thicker by 1/3" and is less prone to failure. These hubs will fit on 240z, 260z and 280z front suspension.
Our engineers added material inside and out to add strength and durability. The inner bearing race mount has been filled in for extra support. These hubs will be able to withstand hard track use as well as daily street use!
Bolt pattern for wheel mounting are 4x114.3MM (4x4.5 Inch) same as 280z.
Bolt pattern for rotor mounting are 4x103MM
These bolt patterns are the same as the 280z front hub
Each set of hubs will come with brad new bearings and races, and stock length wheel studs (stock M12x1.25 thread size). instead of press in wheel studs we thread these hubs with M12x1.25 thread so you can use a bolt as your wheels stud.
All of our front brake upgrades can be used with these hubs! Simply order the brake kit you want along with these hubs. We will make sure everything bolts right up for you.
Remember you now have a 280z hub, so your brake kit needs to be for a 280z front hub, not a 240z.
You can use these hubs with any of our brake upgrades. Or stock 280z brakes.
